Shunting Signals
Sabik’s Shunting Signals are designed with versatility in mind, allowing for easy adaptation to meet different country-specific requirements. Featuring a robust stainless steel enclosure with a matte black finish, these signals are built for durability in demanding environments. Equipped with power LED technology, they offer flexibility in terms of light intensity, beam width, and color, ensuring reliable performance tailored to various operational needs.
RSSL100
- Light generation with 8 power LEDs using low current for enhanced reliability
- Automatic nighttime dimming based on input voltage or power levels
- Wide operational voltage range of 6.0-14.0 VAC
- Unique Line Test for stable on/off performance, regardless of power variations
Product Information
The RSSL 100.12 is Sabik’s latest generation shunting signal, equipped with advanced power LED units designed for high reliability. The signal housing is constructed from stainless steel with a matte black finish, providing durability and a modern aesthetic. The RSSL 100 can be easily adapted for different market specifications, and its innovative light unit architecture ensures safe and efficient operation across various interlocking systems and environmental conditions, such as cable type, length, and signal transformer specifications.
Product Features
- Optical feedback for monitoring each LED individually
- Adjustable power consumption using a Dummy Load power resistor
- A range of customizable operational parameters, including current consumption, luminous intensity, and turn on/off delays
- Wireless IrDA or serial cable connection for accessing and modifying system parameters
